Automatic Testers |
|
 |
|
|
|
|
|
A universal test system was especially developed for the everyday rough industrial
usage in laboratories, workshops as well as a semi- or fully automatic component in a
production line.
As the tester is built-up by different modules, it allows optimum combinations for different tests.
Features:
- Menu controlled test runs: manually and fully automatic;
- The tests switching is automatic by through an extendable matrix relay;
- Test paths combination, test parameters, limit values as well as test vectors set are freely programmed by the user;
- LC-display or large touch screen TFT-display;
- EUT acoustic / visual fail signal alarm and data measurement storage;
- Power-on self-test and permanent intelligent fault management;
- Voltage and current applied and removed in a ramp mode to avoid extra voltage and extra current for EUT protection; ;
- Monitoring of the test cables for cable breakage and contact;
- Test plan database and result memory;
- fully developed apparatus periphery for PLC, RS232, CAN, driver, printer, barcode
reader or Ethernet, USB, keyboard, PS/2 etc;
- PC-driver for customer specific applications (DLL, Active-X and LabView) available;
- Freely programmable input/output, digital interface for status display and
remote control;
- Connections for safety circuits ad warning lamps as required by EN 50191;
- Update Capabilities: your future safe investment.
|
|
|
|
|
|
